Mercusys MW330HP User Manual

MW330HP
300Mbps High Power Wireless N Router
• Username/Password - Enter the username and password provided by your ISP. These
fields are case-sensitive.
• IP Address/DNS Server - Displays the current IP address/DNS server of your device.
Click Save to make your settings effective.
● Secondary Connection
If you have a secondary connection, select and enter the corresponding parameters.
● Connection Type
• Connect on Demand - In this mode, the internet connection can be terminated
automatically after a specified inactivity period (Max Idle Time) and be re-established when
you attempt to access the internet again. If you want your internet connection keeps
active all the time, please enter 0 in the Max Idle Time field.
Otherwise, enter the number of
minutes you want to have elapsed before your Internet access disconnects.
• Connect Automatically - The connection can be re-established automatically when it is
down.
• Connect Manually - This mode also supports the Max Idle Time function as Connect on
Demand mode. The internet connection can be disconnected automatically after a
specified inactivity period.
Click Save to make the settings effective.
- 14 -

Mercusys MW330HP Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	-90 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11g)	-78 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	-74 dBmW
Ethernet LAN (RJ-45) ports	3
Output current	0.6 A
Output voltage	9 V
Power source type	AC
Antenna gain level (max)	7 dBi
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK

Weight and Dimensions

Depth	127 mm
Width	192 mm
Height	36 mm
