Multinorm/FonS/Poly
32
6 Technical data
6.1 Instrument
6.1.1 General
• Communication: RS 232 serial interface for connection to a PC, fully
opto isolated, 57600 baud, 9 pin D-type connector.
• Memory: approximately 4000 values
• Logger: approximately 4000 values
• Dimensions (WxHxL): 110 x 85 x 220 mm
• Weight: 0.56 kg (without battery)
• Battery: 6 x 1.2 V AA rechargeable, with internal charger
• Display: graphical LCD with backlight, 160 x 160 dots
• Pollution degree: 2
• Protection degree: IP 40
• *Working temperature range: -10 ºC to 50 ºC
• *Storage temperature range: - 20 ºC to 70 ºC
• *Maximum humidity: 95 %RH non-condensing
• Conforms to: Safety: EN/IEC 61010-1
Electromagnetic compatibility (emission and immunity): IEC 61326
*Attention: This data can be changed regarding the temperature ranges of the battery
and the probes.
6.1.2 Universal measuring port 1
• Digital interface
• XLR 5MP connector with custom pin assignment
• Analog voltage measuring input
o for measuring illuminance with A 1092 probe:
Range Accuracy
0.01 lux to 19.99 lux ± (0.01 lux + 0.5% of r.)
20.0 lux to 199.9 lux ± (0.1 lux + 0.5% of r.)
200 lux to 1999 lux ± (1 lux + 0.5% of r.)
2000 lux to 20000 lux ± (10 lux + 0.5% of r.)
o for measuring luminance with A 1132 probe:
Range Accuracy
0.1 cd/m
2
to 39.9 cd/m
2
± (0.1 cd/m
2
+ 0.5% of r.)
40 cd/m
2
to 399 cd/m
2
± (0.5 cd/m
2
+ 0.5% of r.)
400 cd/m
2
to 3999 cd/m
2
± (1 cd/m
2
+ 0.5% of r.)
4000 cd/m
2
to 40000 cd/m
2
± (10 cd/m
2
+ 0.5% of r.)
