METREL Multinorm MI 6201 - Universal Measuring Port 2; Thermocouple Port Type K; Probe Adapter Specifications; Probe Adapter General

Multinorm/FonS/Poly
33
6.1.3 Universal measuring port 2
• Digital interface
• 9 pin D-type connector with custom pin assignment
• 5 V and 18 V supply voltage for probes through probe adapter (A 1144)
6.1.4 Thermocouple measuring port type K
• Standard thermocouple K type input
Range Accuracy
-200 °C to +1400 °C ±(1.0 °C + 0.2% of r.)
6.2 Probe adapter (A 1144)
6.2.1 General
• Dimensions (WxHxL): 30 x 35 x 140 mm
• Weight: 0.07 kg
• Working temperature range: -10 ºC to 40 ºC
• Storage temperature range: - 20 ºC to 70 ºC
• Maximum humidity: 95 %RH non-condensing
• Conforms to: Safety: EN 61010-1
Electromagnetic compatibility (emission and immunity): EN 61326
6.2.2 Instrument side:
• Digital interface
• 9 pin D-type connector with custom pin assignment
• 5 V and 18 V supply voltage inputs
6.2.3 Probe side:
• 5 pin Mini XLR connector with custom pin assignment
• Digital interface
• 5 V and 18 V supply voltages for the probes
• Demodulator
• Two analog voltage measuring inputs for measuring temperature and relative
humidity:
o Relative humidity:
Range Accuracy
0 %RH to 100%RH ± 0.1 %RH
o Temperature:
Range Accuracy
-40 ºC to +60 ºC ± 0.1 ºC
