5.1 The display
774 Oven Sample Processor, Instructions for use
43
5 Detailed description
5.1 The display
The display consists of two lines, each having 24 characters.
The first line serves as a title line in which the current method and the sam-
ple counter reading are displayed. In edit mode the menu title is shown.
The second line serves as a status line which displays specific activities
depending on the operating state. In edit mode it serves as an entry line.
Normal state
sample counter Ð
method name Î
oven temperatur Î
******** counter 1/36
110°C 55 mL/min ready
Í instrument status
Ï gas flow
Method processing
running sequence Î
******** counter 2/36
START 03 WAIT 11 s
Í parameter
Ï current command with line number
Mesured values
gas flow 55 mL/min
oven temp. 110°C
Using key <SELECT/DISPLAY>, you can switch back to
measured value display at any time
Edit mode
Ð Menu title
menu line or command Î
>sample sequence
1 MOVE 1 : sample
Í second parameter
Ï first parameter
