5 Detailed description
774 Oven Sample Processor, Instructions for use
108
5.10.3 &Config
Object Description Input range Reference
& Root
:
├ Config Instrument configuration -
: ├ .Aux Miscellaneous - 5.11.2.1
│ ├ .Language Dialog language english, deutsch
│ │ français, español
│ ├ .Contrast Display contrast 0...3...7
│ ├ .Beeper Beeper on/off on, off
│ ├ .DevName Instrument identification 8 ASCII characters
│ ├ .Prog Program version read only
│ ├ .MaxLift Max. Lift height 0...90...100 mm
│ └ .MonBeak Beaker sensor on/off on, off
│
├ .OvenSet Ofen settings - 5.11.2.2
│ ├ .InitTemp Initial temperature Off, 50…250
│ ├ .MaxTemp max. temperature 50...275
│ └ .TempCorr Temperature correction -10…0…10
│
├ .RackDef Rack definitions - 5.11.2.2
│ ├ .RackNo Rack number 1...16
│ ∗ 5.11.2.4
│ ├ .Code Rack code 000001(b)...111111(b)
│ ├ .Type Rack type M36-0, M12-0, M14-0, …
│ ├ .WorkH Work position 0...100 mm
│ ├ .RinseH Rinse position 0...100 mm
│ ├ .ShiftH Shift position 0...20 mm
│ ├ .SpecialH Special position 0...100 mm
│ └ .SpezBeak Special beaker positions 5.11.2.5
│ ├ .1 Special beaker 1 -
│ │ └ .Pos Beaker position 0...number of rack pos.
│ :
│ └ .8 Special beaker 8
│ └ .Pos Beaker position 0...number of rack pos.
│
├ .PosTab Position table - 5.11.2.6
│ ├ .Idx Index of the table 0...31
│ ∗ 5.11.2.7
│ ├ .Name Name of the position table 8 ASCII characters
│ ├ .R1Num Highest beaker pos. in row 1 2...(R2Num – 2)
│ ├ .R2Num Highest beaker pos. in row 2 (R1Num + 2)...(R3Num – 2)
│ ├ .R3Num Highest beaker pos. in row 3 (R2Num + 2)...200
│ ├ .R1Off Offset in
1
/
10
-ang. degr. for R.1 0...3599
│ ├ .R2Off Offset in
1
/
10
-ang. degr. for R.2 0...3599
│ ├ .Num Number of positions 1...200
│ ├ .1 Position 1 -
│ │ └ .Value Position in 1/10-ang. degr. 0...3599
│ :
│ └
.12, 14, 16, 24, 48, i.e. PosTab.Num
: └ .Value Position in
1
/
10
-angular degr. 0...3599
