5.2 The keyboard
774 Oven Sample Processor, Instructions for use
45
5.2.1 Individual key functions
Key Normal state Editing
CONFIG
Opens the configuration Menu
• The <Config> key opens the
selection menu for the con-
figuration of the sample
changer.
• The settings in the Configura-
tion Menu remain constant un-
til they are changed or the
working memory (RAM) is re-
initialized.
Select configuration settings
• When the Configuration Menu
is open, pressing the
<CONFIG> key displays the
next menu line.
• After the last line is displayed,
the first one follows.
• <Quit> exits the menu.
PARAM
Open the parameter menu
• The <Param> key opens the
selection menu for the
changer and dosing settings.
• All settings that are set in the
Parameter Menu belong to a
method and will be saved with
the method. These parame-
ters are method-specific.
• The settings in the Parameter
Menu also apply to Manual
mode.
Select method parameters
• When the Parameter Menu is
open, pressing the
<PARAM> key displays the
next menu line.
• After the last line is displayed,
the first one follows.
• <Quit> exits the menu.
USER
METHOD
Open the user method menu
• The <User Method> key
opens the selection menu for
the loading, saving and dele-
tion of user-defined methods.
Select method functions
• When the User Method Menu
is open, pressing the <USER
METHOD> key displays the
next menu line.
• After the last line is displayed,
the first one follows.
• <QUIT> exits the menu.
HOME
Bring lift to zero-position
• The <Home> key runs the lift
of the active tower to the zero-
position (0 mm), i.e. to the
upper stop.
Select the first line of a menu
• With the <Home> key, the
first line in a menu or a se-
quence can be accessed.
• Any data that has been altered
in a menu or command line is
not carried over. See
<ENTER> key.
