Basic components
13
No. Name Description
1 Status indicator
Displays the current status of the device:
z
Green: the device is running.
z
Blue: the device is in standby status.
z
Red: an error occurs.
z
Yellow: a warning appears, but the device
keeps running.
2 Supporting feet Supports the main unit to ensure stability.
3
Latch of
the reagent
compartment
Press the button on the latch, and pull
the pop-up ring to open the reagent
compartment door.
4
Reagent
compartment
Holds the reagent cartridge and tube at
appropriate temperatures.
5 Buzzer
Alerts when the warnings appear or errors
occur.
6
Touch screen
monitor
Facilitates on-screen operation and displays
information.
