Specifications
63
Specifications
Item Description
Category
The device not in IVDD annex II and not for
self-testing/performance evaluation
Laser classification of the
device
Class 1 laser product
Dimensions
1086 mm
×
756 mm
×
710 mm
(42.8 inches
×
29.8 inches
×
28 inches)
Net weight Approximately 193 kg (425.5 lb)
Touch screen
z
Type: LCD
z
Size: 20 inches
z
Resolution: 1920
×
1080 pixels
Power
z
Voltage: 100 V to 240 V
~
(10%
tolerance)
z
Transient over-voltage category:
Ⅱ
z
Frequency: 50/60 Hz
z
Rated power: 1200 VA
Fuse specification F10AL250V
Maximum sound pressure
level
75 dB(A)
Degrees of protection
provided by enclosures (IP
Code)
IPX0
Accompanying items Refer to the packing list
Operating environment
requirements
z
Temperature: 19 ℃ to 25 ℃ (66 ℉ to 77
℉ ) indoor used only
z
Relative humidity: 20% RH to 80% RH,
non-condensing
z
Atmospheric pressure: 70 kPa to 106
kPa
z
Maximum altitude: 3000 m (9843 ft)
