Device overview
20
No. Name Description
7 Reagent container
Holds the reagent cartridge at
appropriate temperatures.
z
Reagent cartridge A is placed on
the left. It provides the required
reaction components for flow cell
A.
z
Reagent cartridge B is placed on
the right. It provides the required
reaction components for flow cell
B.
8
Reagent compartment
door
You can press the button on the latch
of the door, and pull the pop-up ring
to open the door.
Control software
The system control software initiates the communication protocol
through physical ports to coordinate with the hardware, control
gas lines, fluidics lines, temperature, mechanical components,
and optical components. The software detects the signal on the
sequencing flow cell, transfers the photographic information to the
base sequence files in standard format, and guides different users to
perform different processes, such as maintenance and experimental
protocols.
The following table describes the function of each functional
module:
Item Description
Self-test
Checks whether the components of the system are
functional.
Sequence Performs different types of sequencing processes.
Wash
Performs wash and maintenance for fluidics lines of the
system.
Software
running
Monitors the components status of the system.
