Sequencing
38
If there is no QR code on the tube, type the serial number of the
tube with the on-screen keyboard or the physical keyboard.
4. Select a barcode range from the list on the right of DNB ID box.
Tap
or
to add or remove a line of DNB ID if needed.
5. Remove the lid of the tube. Open the reagent compartment door,
and insert the tube into the tube rack as shown in the following
figure. Ensure that the tube is securely seated.
6. Press down the base and ensure that the needle tip reaches the
bottom of tube.
Figure 12 Moving the needle
7. Select a sequencing recipe from the Recipe list. Select the DNB
loading check box if needed.
8. Tap Next.
