Instructions SL1 29
FL1 Flashing light
Type
Flashing signalling light for automatic gates and doors. The device incorporates a receiving aerial for
remote control
Adopted technology
Visual signalling device with 12V 21W lamp, controlled by MHOUSE automation control units
Lamp
12V 21W BA15 socket (automotive type lamp)
Power supply
The device can be connected only to the "FLASH" and "AERIAL" terminals on the MHOUSE automatic
gate control units
Operating ambient temperature
-20 ÷ 50°C
Suitable for use in acid, saline or
potentially explosive atmosphere
No
Mounting
Horizontal surface-mounted or vertical wall-mounted
Protection class
IP55
Dimensions / weight
120 x 60 h 170mm / 285g
KS1 Key-Operated Selector Switch
Type
Key-operated double switch suitable for control of automatic gates and doors. Illuminated for night
operation
Adopted technology
Activation protected by a lock, the insertion and clockwise turning of the key causes the closing of a
contact , the counter-clockwise turning of the key causes the closing of the second contact; spring-loaded
for return of key to the middle position
Tamper-proof
The selector switch can be opened to access the connections only by inserting the key and turning it in
either direction
Security lock
Key with 450 different key numbers
Power supply/contacts
The device can only be connected to the "OPEN" and "STOP" terminals on the MHOUSE automation
control units, to which it sends the control signals and by which it is energized for night illumination
Operating ambient temperature
-20 ÷ 50°C
Suitable for use in acid, saline or
potentially explosive atmosphere
No
Mounting
Vertical, wall mounted
Protection class
IP44
Dimensions / weight
95 x 65 h 36mm / 135g
PH1 Photocells
Tipologia
Presence detector for automated gates and doors (type D according to EN 12453 standard) consisting of
a "TX" transmitter and an "RX" receiver
Adopted technology
Optical, by means of direct TX-RX interpolation with modulated infrared ray
Detection capacity
Opaque objects located on the optical axis between TX and RX, larger than 50mm and moving slower than
1.6m/s
TX transmission angle
Approx. 20°
RX reception angle
Approx. 20°
Useful capacity
Up to 10m for maximum TX-RX misalignment of ± 5° (the device can signal an obstacle even in the case of
adverse weather conditions)
Power supply/output
The device can be connected only to "ECSBus" networks from which it receives the power supply and
sends the output signals.
Absorbed power
1 ECSBus unit
Maximum cable length
Up to 20m (observe the directions regarding the minimum gauge and type of cable)
Addressing possibility
Up to 7 detectors with protection function and 2 with opening command function.
The automatic synchronism prevents any interference among the various detectors
Operating ambient temperature
-20 ÷ 50°C
Suitable for use in acid, saline or
potentially explosive atmosphere
No
Mounting
Vertical, wall-mounted
Protection class
IP55
Dimensions / weight (TX and RX)
95 x 65 h 25mm / 65g
