SL1K gearmotor for sliding gates
Type
Electromechanical gearmotor for automated gates and doors incorporating a control unit complete with
radio receiver for "TX4" transmitters.
Adopted technology
24Vdc motor, helical teeth reduction gear; mechanical release A transformer inside the motor but separated
from the control unit reduces mains voltage to the nominal voltage of 24Vdc used by the automation system
Peak thrust
18Nm
Nominal torque
10Nm
Nominal thrust
330N
Idling speed
0,18 m/s in "slow" speed mode; 0, 26 m/s in "fast" speed mode
Nominal torque speed
0,14 m/s 0.14 m/s in "slow" speed mode; 0, 20 m/s in "fast" speed mode
Maximum frequency of cycles
50 complete cycles per day (the control unit allows up to a maximum of 10 cycles per hour)
Maximum continuous cycle time
approx. 13 minutes
Working Limits
Its structural characteristics make it suitable for use on gates weighing up to 350Kg and up to 5m long
Power supply
230Vac (+10% -15%) 50/60Hz
Rated absorbed power
100 VA; peak power is 250 VA for maximum 3s
Emergency power supply
Designed to accommodate "PR1" buffer batteries
Flashing light output
For visual signalling devices with 12V lamp, maximum 21W
ECSBus output
One output with a maximum load of 10 ECSBus units
"OPEN" input
For normally open contacts (the closing of the contact causes the "OPEN" command)
STOP input
For normally open contacts and/or for 8.2Kohm constant resistance, or normally closed contacts with
recognition of the "normal" status (any variation from the memorized status causes the "STOP" command)
Radio aerial input
52 ohm for RG58 or similar type of cable
Maximum cable length
Mains power supply: 30m; inputs/outputs: 20m with aerial cable preferably shorter than 5m (observe the
directions regarding the minimum gauge and type of cable)
Operating ambient temperature
-20 ÷ 50°C
Not suitable for use in acid, saline or
potentially explosive atmosphere
No
Mounting
Horizontal surface-mounted with relative fixing plate
Protection class
IP54
Dimensions / weight
300 x 163 h 295 / 9 Kg
Remote control possibility
With TX4 transmitters the control unit can receive one or more of the following commands: "OPEN", "Open
partially", "Open only" and "Close only"
TX4 transmitters memorized
Up to 150 if memorized in mode 1
Range of TX4 transmitters
From 50 to 100m. The range can vary if there are obstacles or electromagnetic disturbances, and is affected
by the position of the receiving aerial incorporated in the flashing light
Programmable functions
"Cycle" or "Complete cycle" operation (automatic closing)
"Slow" or "fast" motor speed
The pause time in the "complete cycle" mode can be set at 10, 20, 40, 80 seconds
The type of pedestrian opening can be selected from 4 modes
The sensitivity of the obstacle detection system can be selected from 4 levels
The operation of the "Open" command can be selected from 4 modes
Self-programmed functions
Automatic detection of devices connected to the ECSBus output
Automatic detection of the type of "STOP" device (NO or NC contact or 8.2Kohm resistance)
Automatic detection of gate length and calculation of deceleration points
