2.0 Quick Start
2.2.1 Configuring the Access Point (Con’t)
 Configure the pX2 as an Access Point
In the Radio1 Virtual Interface sec-
tion, select Access Point from the
Mode dropdown box.
Select Wireless from the top/main navi-
gation, and then Radio1 from the sub-
menu list.
Enter a unique SSID as shown.
TESTSSID
For bench or close proximity testing it
is best to use a lower power setting to
prevent RF saturation. Select 20dBm
from the TX Power setting.
The remaining settings in the
Wireless menu should be left as
defaults for this exercise.
Click on the Submit button to
write the changes to the pX2. The
Cancel button will revert back to
previously saved values.
If any additional
settings need to be
changed, ensure they
are also changed on
the Station.
