Microhard Systems pX2 - Quick Start Guide; Getting Started

© Microhard Systems Inc. 14
2.0 Quick Start
To reset to factory
defaults, press and
hold the CONFIG for 8
seconds with the pX2
powered up. The pX2
will reboot with factory
default settings.
This QUICK START guide will walk you through the setup and configuration of a few
basic applications. The QUICK START will rely on the WebUI for configuration. This
walkthrough also assumes the units used are installed in microhard interface/
development boards or custom boards that allow access to the LAN port. See the
appropriate section for pin-outs.
Note that the units arrive from the factory with a Radio Configuration of ‘Access
Point’ and the Local Network setting configured as ‘Static’ (IP Address
192.168.168.1, Subnet Mask 255.255.255.0). DHCP is enabled by default, and will
assign an IP to a connected device.
2.1 Getting Started
 Connect an appropriate Antenna to the ANTENNA connector of the pX2.
 Connect and/or apply a suitable power source to the unit.
 Connect A PC to the LAN port (eth0) of the pX2, using an Ethernet Cable.
 The PC must have its Network Setting (TCP/IP Properties) set to DHCP (The mo-
dem will assign a IP address to you), or STATIC with an IP Address of (e.g.)
192.168.168.10 and a Subnet Mask of 255.255.255.0.
The factory default
network settings:
IP: 192.168.168.1
Subnet: 255.255.255.0
Select Internet Protocol (TCP/IPv4)
and then Properties.
To set a Static IP, in Windows 7 the TCP/
IP Properties can be found in:
Start > Search Bar “Network and Sharing
Center”
Select “Change Adapter Settings” on the left
menu, and the right click the Ethernet
adapter connected to the pX2.
