2.0 Quick Start
2.2 Simple Access Point and Station/Client
This Quick Start example requires (2) pX2 modules, one will be configured as a
Access Point (AP), the second unit will be configured as a Station/Client (ST). This
example will show the basic steps required to set up each unit so that a simple net-
work will be established.
2.2.1 Configuring the Access Point
Use Section 2.1 Getting Started to connect, power up and log in to a pX2 unit.
Give the pX2 unit a unique IP address.
AP ST
Wireless
Select Network from the top/main
navigation.
Select LAN from the submenu list,
and then select Edit.
Choose Static IP for the Connection Type.
Enter the following Network Information:
IP Address: 192.168.168.11
IP Subnet Mask: 255.255.255.0
Click on the Submit button to write the changes to the pX2. The Cancel button will re-
vert back to last values saved to the unit.
Once the IP Address is changed, you will need to type the new address into
your browser to continue the configuration.
To connect to an
existing network,
contact your Network
Administrator for valid
network settings.
