4.0 Configuration

Remote Port

Specify the UDP port number of the Remote IP Address.

*Default Port Numbers for Microhard NMS (20100 for modem events, 20200 for

Management)

Values (Port #)

20200

Interval Time(s)

This is the interval time in seconds, that the pX2 will send the configured

UDP message to the Remote IP and Port specified.

Values (seconds)

600

4.6.1.2 Event Report > Message Structure

Modem_event message structure

- fixed header (fixed size 20 bytes)

- Modem ID (uint64_t (8 bytes))

- Message type mask (uint8_t(1 byte))

- reserved

- packet length (uint16_t(2 bytes))

Note: packet length = length of fixed header + length of message payload.

Message type mask

Modem info - 2 bits

00 no

01 yes (0x1)

Carrier info - 2 bits

00 no

01 yes (0x4)

WAN Info - 2 bits

00 no

01 yes (0x10)

sdp_event message structure

- spd_cmd (1 byte(0x01))

- content length (1 byte)

- spd_package - same as spd response inquiry package format

Message Info Type

When Modem_Event is selected, up to three different payloads can be

selected.

Values (seconds)

Modem

Carrier

WAN
