4.0 Configuration
Source IPs
Match incoming traffic from the specified source IP range. Boxes accept
single IP Addresses without network masks, example: 192.168.1.0 to
192.168.1.255 represents all IP Addresses in the 192.168.1.0/24 network.
(Put same IP in both boxes for a single IP match.)
Values (IP Address)
192.168.0.0 to
192.168.0.0
Destination
Select the zone which is the intended destination of the data traffic.
Values (selection)
LAN/LAN1/WAN/WIFI
None
Destination IPs
Match incoming traffic from the specified destination IP range. Boxes
accept single IP Addresses without network masks, example: 192.168.1.0
to 192.168.1.255 represents all IP Addresses in the 192.168.1.0/24
network. (Put same IP in both boxes for a single IP match.)
Values (IP Address)
192.168.0.0 to
192.168.0.0
Destination Port
Match incoming traffic directed at the given destination port or port range.
(To specify a port range use a From:To (100:200) format)
Values (port)
0
Protocol
The protocol field defines the transport protocol type controlled by the rule.
Values
TCP
UDP
Both
ICMP
