4.2 Telnet/SSH – View Menu
Telnet/SSH View option provides information on PoE ports status, network in-use parameters, and unit
information.
Figure 4-2: Telnet/SSH View Menu
4.2.1 Telnet/SSH– View PoE Ports Status
View PoE ports status provides Network plus PoE power consumption information for each one of the ports,
plus overall power consumption and internal power supply voltage.
Figure 4-3: Telnet/SSH View PoE Ports Status
Network
Reports Ethernet link speed (10/100/1000) and HD/FD connection type
PoE
Power consumption by each PD device
Total Power
Total power consumption of all PDs from all active PoE ports plus
maximum available power
Power Supply
Unit internal power supply voltage
