2.2 System Network Management Capabilities
The unit can be accessed from any computer using any Web browser, SNMPv2c/SNMPv3 management
station, Telnet/SSH.
 Web Interface – used to view unit PoE and network status, unit configuration and view unit production
information.
 SNMP v2/v3 – Monitor unit over the network (MIB-II RFC1213), monitor / configure unit PoE
capabilities (RFC3621).
 Telnet/SSH – used to view unit PoE and network status, unit configuration and production information.
Software update, enable/disable PoE functionality, ping remote network devices for connectivity tests.
 SNMP Traps – used to report various PoE events such as PoE PD insertion / removal.
 SysLog – used to report PoE events, invalid remote user access, initial DHCPv4/v6 address, etc.
2.3 Ethernet Switch Network Capabilities
 10Mbit/100Mbit/1000Mbit Half-Duplex / Full-Duplex Ethernet speed
 8K internal MAC address lookup engine
 Auto MDIX
 Jumbo frames
2.4 PoE Capabilities
The following PoE options are available:
 Two 4Pair PoE Ports - Delivers up to 60 watts per port.
 Two IEEE 802.3at – Delivers up to 30 watts per port.
 PoE Enable/Disable – Enable/disable PoE ports power output (Ethernet data is always enabled).
 Weekly Schedule PoE Port Reset – Automatic PoE Ports reset based on time of day.
 Weekly Schedule PoE Port Activation – Automatic activation/deactivation of PoE ports based on time
of day (Ethernet data flow for disabled PoE port remains enabled, however no PoE power is being
applied).
 Remote device reset – Turning temporary device power off and back on resets attached PD device.
2.5 Configuration Options
 Web-based: Via a Web browser (HTTP/HTTPS)
 SNMPv1/2c/3: Via an SNMP management application on a remote computer
 Telnet/SSH: Via a Telnet/SSH client on a remote computer. Please note that by default the unit
is shipped with Telnet enabled and SSH disabled.
NOTE:
The unit default IPv4 address is 192.168.0.50. Make sure that a computer network card is
configured to the same IPv4 network (for example 192.168.0.40).
NOTE:
For security reasons, when the unit is shipped the SNMP is disabled. Prior to enabling
SNMP, modify SNMP community strings and only then enable it.
2.6 Security and User Authentication
Web HTTPS/HTTPS, Telnet/SSH, SNMPv2 and SNMPv3 offer different security strength
