Rear Panel
n IRIG B 1344 DCLS
n IRIG B AM Legacy TrueTime
n IRIG B DCLS Legacy TrueTime
n IRIG E
n IRIG E AM 100Hz (with year)
n IRIG E AM 1KHz (with year)
n IRIG E DCLS (with year)
n IRIG E AM 100Hz (no year)
n IRIG E AM 1KHz (no year)
n IRIG E DCLS (no year)
n IRIG G
n IRIG G AM (with year)
n IRIG G DCLS (with year)
n IRIG G AM (no year)
n IRIG G DCLS (no year)
n NASA36
n NASA36 AM
n NASA36 DC
n XR3/2137
n XR3 250Hz
n 2137 1kHz
n XR3 DC
IRIGOut(TimecodeOut)
Description:IRIG Out, provides a selected time code from the SyncServer's Hardware Clock. The
time code format is selected via the Web interface. Amplitude Modulated (AM) and DC Level
Shifted (DCLS) outputs are supported from the IRIG Out BNC. Also see REFERENCES -
Timecode (on page 71) and IRIG Control Function Bits (on page 120).
Connector:IRIG Out, BNC female
DCLS Amplitude: TTL into 50 ohms
AM Amplitude:3.5 ±0.5 Vpp into 50 Ohms
AM Ratio:3:1 ±10%
Selectable Time Code Output Formats:
IRIG A IRIG B IRIG E
A000 (DCLS, CF, SBS) B000 (DCLS ,CF, SBS) E001 (DCLS, CF)
A001 (DCLS, CF) B001 (DCLS ,CF) E002 (DCLS)
A002 (DCLS) B002 (DCLS) E005 (DCLS, YR, CF)
A003 (DCLS, SBS) B003 (DCLS ,SBS) E006 (DCLS, YR)
A004 (DCLS, YR, CF, SBS) B004 (DCLS ,YR, CF, SBS) E111 (100 Hz, CF)
997-01520-02 Rev. F1.......................................................................... Page 119
