Configuring the SyncServer
S300, S350 and S350i Quick Start Guide
In this section
Configuring the SyncServer 13
Status LEDs 15
Halting the SyncServer 15
This topic guides the user on how to:
n Configure a SyncServer that still has its original factory configuration.
n Read the status LEDs on the front panel.
n Shut the SyncServer down correctly.
For more information about the features and tasks described here, consult the following sec-
tions in the main User Guide:
n Web Interface (on page 21)
n Keypad/Display Interface (on page 101)
n Specifications (on page 111)
n Tasks (on page 135)
For your convenience, cross references in this Quick Start Guide provide the page numbers
of topics in the main User Guide.
Configuring the SyncServer
Recommended Tasks
GPS antennas not rated for 12 VDC power may be damaged if connected to the SyncServer.
1. Mount the standard L1 GPS antenna (supplied) in a location that offers good visibility of
GPS satellites, such as a rooftop or outdoor antenna mast with wide open views of the
sky and horizon. Avoid obstructions and sources of Radio Frequency Interference.
Observe building codes and regulations. Also see Using GPS (on page 140) and
WARNING: GPS Antenna (on page 132).
a. Note: For the SyncServer 350i, which doesn't have a GPS receiver, connect an
IRIG signal to the IRIG In connector on the rear panel and skip references to GPS and
antennas in the rest of this procedure.
2. On the rear panel:
n
Connect the GPS antenna cable (supplied) to the GPS Ant connector.
n
Connect LAN1 and any of the other network ports to the network.
997-01520-02 Rev. F1.......................................................................... Page 13
