Status LEDs
Status LEDs
The four tricolor LEDs provide the following status information:
Red Orange Green Dark
Sync
SyncServer is
not synchronized
to a
reference.
NTP Stratum 16.
SyncServer is syn-
chronized to a remote
NTP server.
NTP Stratum 2-15.
SyncServer is synchronized to
an Input Reference or the
modem
1
.
NTP Stratum 1.
Power off.
Network
Link failure on the
LAN1.
Link failure on the LAN2,
LAN3, or LANGBE.
All configured ports operational. Power off.
NTP
>7000 NTP pack-
ets per second.
> 5000 packets per
second.
NTP activity within the last
second.
No NTP
activity in
the last
second.
Alarm
Major Alarm. Minor Alarm. No Current/Enabled Alarms. Power off.
Also see Stratum (on page 202).
Halting the SyncServer
Microsemi recommends shutting the operating system down before removing the power.
Using the keypad/display interface:
1.
Press the MENU button.
2.
Select 3) Sys Control.
3.
Select 2) Shutdown.
4.
Press the ENTER button.
5. When the display shows "System Stopped - OK to Turn Power Off Now!" turn the power
off.
Or, using the web interface:
1.
Go to the SERVICES - Startup page.
2.
Select Halt and click the APPLY button.
3. Wait approximately 30 seconds before removing power.
1
The SyncServer S350i does not include a modem.
997-01520-02 Rev. F1.......................................................................... Page 15
