STATUS - Timing
Hardware Clock Status
Current Sync Source: The Input Reference currently used by the Hardware Clock. Consult the
TIMING - HW Clock topic for more information.
Hardware Clock Time: The time according to the Hardware Clock.
Hardware Clock Status: "Locked" means the Hardware Clock is synchronized to one of its ref-
erences, or to the internal oscillator in "Holdover". "Unlocked" means the Hardware Clock
doesn't have an Input Reference and the Holdover period has expired. Also see TIMING -
HW Clock (on page 61) and TIMING - Holdover (on page 63).
Oscillator Type: The type of the oscillator installed in the Hardware Clock for operation and hol-
dover.
For each of the following Input Status lines, "Locked" means that the reference is valid and
can be selected by the Hardware Clock. "Unlocked" means the reference is not valid, and is
therefore not available for use by the Hardware Clock. Also see TIMING - HW Clock (on
page 61) to arrange the priority of the Input References.
Some of these references are options or are only available in specific SyncServer models.
(Consult Product Overview (on page 17) for more information about features and models):
n *GPS Input Status (note, the 350i SyncServer does not have a GPS receiver)
n Timecode Input Status
n 1PPS Input Status
n 10MHz Input Status
n LFR Input Status
* The SyncServer S350i does not have a GPS receiver.
Leap Warning: The state of the Leap Indicator (on page 197) as reported by the current input
reference.
STATUS - GPS
GPS Receiver Operation
1
This page displays the status of the GPS Receiver.
Receiver Description: "GPS" indicates the presence of a 12-channel GPS receiver.
Receiver Status:
n Receiver Down: The Hardware Clock can't communicate with the receiver.
n Unknown Mode: An undefined mode of the GPS receiver.
n Acquiring Signal: The receiver is attempting to track a GPS signal.
1
The SyncServer S350i does not include a GPS receiver.
