CHAPTER III Sequence Test Setup
APTER III Sequence Test SetupAPTER III Sequence Test Setup
APTER III Sequence Test Setup
P 43
(i) The Items Exposition
 Trigger Mode Press S1[PROG] to shift setting to be MANUAL／
AUTO. When this function is ON, the system will
scan cable whether connect with fixture or not. If so,
the system will start testing automatically, when the
setting is OFF, you can only use [Test] to start test.
 Trigger Delay Use alphanumeric to enter delay times.
 Break Point Press S1[PROG] to shift test setting to be OFF／
O/S／L/V.
 Repeat Test Press S1[PROG] to shift setting to be ON／OFF.
 Repeat Count Use alphanumeric to enter repeated test count. When
the setting is ON, the test count setting is 0, the system
will test repeatedly until run against a fail.
 Repeat interval Use alphanumeric to enter repeated test interval time.
III.2
III.2 III.2
III.2 Run The Sequence Test
After the setup completion of all items you needed, the system is ready to
proceed and run the sequence test routine. For the two occasions will occur
description as below:
III.2.A
III.2.A III.2.A
III.2.A Run The Real Time Sequence Test
This routine is called in applying the setups stored in system memory to process
the sequence test.
 Operation Procedure
(a) Check out all of test setup
(b) Press [Mode] will display test mode setup
(c) Check out and confirm the test mode setup whether correct or not, and
modify if needed.
(d) Press [EXIT] to return to the main screen
(e) Press [TEST] to start test
(f) When finish or need discontinue test, press [EXIT] to leave.
