Microtest CT-8700 - CHAPTER II SYSTEM FUNCTION AND CONFIGURATION; II.1 SYSTEM FUNCTION

CHAPTER
CHAPTER CHAPTER
CHAPTER Ⅱ
ⅡⅡ
Ⅱ System Function & Configuration
System Function & Configuration System Function & Configuration
System Function & Configuration
P 3
I.4
I.4 I.4
I.4 Tester Tour
I.4.A
I.4.A I.4.A
I.4.A The Front Panel
(1) LCD Display
(2) S1~S6 SoftKeys
(3) PASS & FAIL & HIPOT LED Indicator
(4) EditKey Group
(5) MoveKey Group
(6) Fastkey Group
(7) SysKey Group
(8) Power Switch
(9) HV Calibration Output
(10) Pin Search Connector
(11) 256 Pin Fixture Connector Slot (4 Slots are shown with 256 Pins. Only A
and B two slots equipped with standard 128 pins)
