MidNite Classic - Electrical Specifications; Default Battery Charge Set Points

Classic Manual Rev L
65 | P a g e 1 0 - 0 0 1 - 1 R E V L
Electrical Specifications
Model
Classic150
Classic200
Classic250
Operating Volts in
150VDC
200VDC
250VDC
Max Hyper VOC
150 + Batt V*
200 + Batt V*
250 + Batt V*
*Battery Charge Volts
12-93 volts
12-93 volts
12-93 volts
**Absolute Current
Output at 25°C
96a at 12v battery
94a at 24v battery
83a at 48v battery
74a at 12v battery
70a at 24v battery
65a at 48v battery
60a at 12v battery
62a at 24v battery
55a at 48v battery
De-rate current
at 40°C+
80 amperes
66 amperes
52 amperes
Environment
-40C to 40C
Dimensions of Classic
14.87”X 5.95”X 4.00” 378mm X 151mm X 102mm
Dimensions of Box
19.00”X 8.50”X 5.70” 483mm X 216mm xX145mm
Shipping Weight
11.5 lb 4.9 kg
NOTE: Current output ratings were measured with 75% of the PV array’s Voc (Open Circuit Voltage)
*NOTE: Calculated by adding battery nominal voltage to the maximum input operating voltage (48V battery
max)
* **NOTE: Measurement Accuracies: +/- 0.12V, offset calibration adjustment maybe necessary
Table 4
Default Battery Charge Set Points
The table below describes the default preset voltages for the different nominal battery voltages.
This means that if you set the Classic from the QUICK START to a different battery voltage, the
Classic will take the default voltage set points. If you manually adjust the Absorb, Float, or
Equalization voltage set points, and then nominal battery voltage is changed to a different nominal
voltage, (i.e., from 24V to 12V), manual adjustments may be required.
Battery
Voltage
12v
24v
36v
48v
60v
72v
Bulk MPPT
14.3v
28.6v
42.9v
57.2v
71.5v
85.8v
Float
13.6v
27.2v
40.8v
54.4v
68.0v
81.6v
Equalize
14.3
28.6v
42.9v
57.2v
71.5v
85.8v
Table 5
Optional Accessories
Blank MNGP for multiple Classic installations.
MidNite network cable, 3 ft.
