Classic Manual Rev L
10 | P a g e 1 0 - 0 0 1 - 1 R E V L
of 180V. The same set-up using higher voltage modules that result in a 200V maximum power
voltage will result in only 53A. Although 55A to 53A is not a significant change, it does indicate that
a lower input voltage is more productive. Design your system to achieve an ideal input voltage, or a
“sweet spot,” in terms of sufficient Voc for MPPT operations: not too low, not too high. Keep in mind
that an MPPT controller needs to have the open circuit voltage of the array about 33% higher than
the highest battery voltage you plan to charge to.
NOTE: You can find the Classic string sizing tool our web page www.midnitesolar.com.
Classic Installation
Unpacking the Classic
When you receive your Classic, you will want to unpack it and make sure everything is there and in
good shape. Refer to Figure 1. Included with the Classic:
Classic charge controller
Battery temperature sensor
User’s manual, printed
Knock out covers, 3 screened
Parts bag with stickers, terminal block cover, and silicone grease
Email customerservice@midnitesolar.com for more information or if anything is missing or
damaged.
Figure 1
Removing and Installing Classic Front Cover
Removing the front art deco cover is required to gain access to the wiring compartment.
NOTE: A cable connects the cover to the electronics. Do not pull hard or fast as damage could occur.
