Technical Information
T300 Series Clothes Dryer (Condenser)
1.7 Electrical Connection
(German standard models only!)
Voltage:
220V, 50Hz
Connection
Load:
3.3 kW
Heater Rating:
2.94 kW
Fuse Rating:
16 A
Supply Lead:
3-core with Plug
Table 1-2: Electrical Connection
1.8 Drive Motor
180 W, with fan 240 W
1.9 Air Circulation Fan
160 W, 130 m
3
/ h
1.10 Cooling Air Fan
110 W, 320 m
3
/ h
1.11 Condensate Pump
Condensate may be drained to the rear. Refer to Section 1.12 – Rear
Drainage.
1.11.1 T 368 C
20 W, Rear drainage not possible until Machine no. 700201 From
Machine no. 7100202 as Section 1.11.2
1.11.2 T 352 C, T 358 C, T 359 C, T 367 C, T 368 C, T 369 C, T 369 C-2,
T 377 C, T 378 C, T 382 C, T 383 C, T 388 C
20 W, Rear drainage possible.
Max. head height 1.5 m
Max. hose length 6.0 m
11
