Technical Information
T300 Series Clothes Dryer (Condenser)
5.0 Service and Maintenance
T 368 C, T 369 C, T 369 C-2, T 377 C, T 378
General Information
Service and repair work should only be carried out by qualified persons in
accordance with local and national safety regulations.
The appliance should be disconnected from the mains before work is
commenced.
5.1 Appliance Lid
5.1.1 Removal
1. Remove the 2 screws, (refer to Figure 5-1 – Opening the Front Panel,
Item 1), from the left and right lid edges.
2. Pull the lid forwards, lift up slightly along the front edge, slide it
towards the rear and remove.
5.2 Front Panel
5.2.1 Opening the Front Panel
Figure 5-1: Opening the Front Panel
21
