Technical Information
T300 Series Clothes Dryer (Condenser)
5.17 Condenser Box
5.17.1 Removal
1. Carry out the work listed in Section 5.13.1 – Drum Removal.
2. Remove the Condensate Pump (refer to Figure 5-15 – Condensate
Pump Replacement, Item 1).
3. Release the cooling pump spring (refer to Figure 5-17 - Cooling Fan
Removal 1).
4. Remove the screw below the condenser box and lift out the box.
Note:
When refitting, ensure that the seal is first inserted; recess down, in the
air duct before fitting the condenser box. Also ensure that the lower edge
of the seal from the cooling fan is correctly located and projects in the
condenser box.
