Miele T300 - Drum; Removal

Technical Information
T300 Series Clothes Dryer (Condenser)
5.13 Drum
5.13.1 Removal
Figure 5-24: Drum Removal
1. Carry out Steps 1-5 of Section 5.12.1 – Drum Drive Belt Replacement.
Note:
From Machine no. 7034881, Step 2 is not required.
2. Models up to Machine no. 7034880, remove the lid or pull the
machine forward slightly out of its recess if built-in.
 Unscrew the fixing bracket (refer to Figure 5-24 – Drum Removal,
Item 1) and remove the inlet hose.
 Remove the upper hinge piece (refer to Figure 5-24, Item 2) and
lift off the front panel.
3. Carry out Steps 8-11 of Section 5.12.1 – Drum Drive Belt
Replacement.
4. If the drum type is shown in Figure 5-25 – Simple, Folded Drum Edge
(see arrow), slacken the bearing screws (Figure 5-23 – Drum Drive
Belt Replacement 3, Items 3 and 4) by one turn.
Figure 5-25: Simple, Folded Drum Edge
42
