Miele T300 - Figure 5-7: Heater Bank Removal 2

Technical Information
T300 Series Clothes Dryer (Condenser)
Figure 5-7: Heater Bank Removal 2
Note:
When refitting the drum rear panel, it is important to ensure that the
bearing housing is correctly aligned at the position indicated by the arrow
in Figure 5-7 and lightly screwed into place.
Then, align a hole in the drum rear panel with one of the captive nuts,
insert a screw and tighten by hand. Turn the drum by hand and fit all the
other screws in the same way one by one, then tighten them.
28
