Miele T300 - Cooling Fan - Circulation Fan Belt; Replacement

Technical Information
T300 Series Clothes Dryer (Condenser)
7. Pull the fan forward by about 2 cm and, by tilting it, lift the rear support
bracket; refer to Figure 5-14 – Removing the Unit, Item 1, to the left
over the U traverse. Remove the unit.
Figure 5-14: Removing the Unit
5.7 Cooling Fan – Circulation Fan Belt
5.7.1 Replacement
1. Open the front panel – Refer to Section 5.2.1.
2. Remove fill ring/exhaust vent duct (refer to Section 5.6.1 – Fan Unit
Removal, Steps 2-5).
3. With the left hand, hold the belt on the pulley of the cooling fan.
4. Turn the circulation fan by hand and ease the belt onto the circulation
fan pulley.
34
