Technical Information
T300 Series Clothes Dryer (Condenser)
Figure 5-10: Fan Unit Removal 2
Note:
When refitting the fan unit, ensure that the wiring harness is correctly
located in the retaining clip on the fan housing. Also ensure that the
connecting hose between the condensate pump and the collection vessel
is laid and, if necessary, fixed so that it does not come into contact with
the drum.
31
