Technical Information
T300 Series Clothes Dryer (Condenser)
1. Refer to Figure 5-1 – Opening the Front Panel.
2. Remove the condensate container drawer to reveal 2 screws (Item 2),
and unscrew them.
3. Remove the 4 screws (Item 3).
4. Open the air grid.
5. Press the spring clip (Item 4) down with the lid opener and open the
front panel.
All components are easily accessible once the front panel has been
opened.
22
