OM-291865 Page 20
5-2. Cobot Installation Site Requirements
R72.44
RESTR
I
C
TE
D
SP
ACE
2
0.0
R92.44
Other Equipment
Building Structure
Do not move or operate unit where
it could tip.
Special installation may be re-
quired where gasoline or volatile
liquids are present - see NEC Ar-
ticle 511 or CEC Section 20.
A risk assessment of the specific installation
location shall be performed to determine
possible trapping or pinch points within the
cobot restricted space.
A minimum of 20 in. (508 mm) of clearance
beyond the restricted space (72.44 in. from
the base of the cobot arm) shall be main-
tained. This includes perimeter barriers, arc
screens, buildings, structures, utilities, other
machines, and equipment not specifically
supporting the cobot function.
Failure to maintain the required
clearance can result in
entrapment.
To Next Page
