Replacing the consumables ________________________________
1. Put the Simplicity into STANDBY mode by pressing the OPERATE button. Do not turn off
the electrical power to the system.
2. Remove the old SimFilter ( Figure 5,B) from the Point of Use valve.
3. Open the Point Of Use valve for a few seconds to depressurize the system.
4. Swing the Pack locking handle (Figure 4,E) to the left by pressing on the locking tab (4,A).
5. Remove the old SimPak (4,D).
6. Remove the two protective caps on the new SimPak. Wet the two O-rings on the pak with
a few drops of water.
7. Push the new SimPak firmly into the unit.
8. Secure the place by closing the locking handle (4,E).
9. Remove the reservoir cap (3,C) and install the Millex vent filter (3,D), shipped with the
SimPak into the inner connector of the reservoir cap.
10. Install the connector (Figure 2,C) into the POU valve.
Note: Do not use Teflon tap on the connector tread
11. Position a container under the outlet fitting.
12. Move the dispensing valve button down to open the valve.
13. Press the OPERATE button to switch from STANDBY to OPERATE mode.
14. After having drawn 1-2 litres of water from the system, close the valve.
15. If possible, leave the system in STANDBY mode overnight. This helps to hydrate the ion
exchange resin inside the SimPak. This only needs to be followed each time a new SimPak
is installed.
16. Remove the connector (Figure 5,A) from the POU valve if installed.
17. Install the SimFilter (5,B) into the POU valve. Do not use teflon tape on the threading.
MAINTENANCE __________________________________________
