MIMAKI CG-100SR2 User Manual

19
Turning the power on
1
Press the “ | ” side of the power switch.
• When the plotter is turned on, it will enter the first
operation mode, which are followed by the
subsequent modes. Refer to page 1-15 for the
operation modes.
2
The POWER indicator lamp lights up
green.
• The sheet suction fan rotates.
3
Check the receiving buffer.
• Then, the tool conditions for the currently selected
tool appears on the LCD.
• Before turning the power on, check that the pinch rollers have been raised.
• Be sure to turn on the host computer before turning on the plotter. If this order is not correctly
followed, the plotter can malfunction.
• Once the power is turned off, wait at least five seconds before turning the power on again.
BOOT
CG I I c - 6 0R * . * *
BUFFER=30720KB
CUT1 20 050 0.30

MIMAKI CG-100SR2 Specifications

General

Brand	MIMAKI
Model	CG-100SR2
Category	Cutter
Language	English
