33
Start cutting (plotting)
1
After completion of setting the origin,
press the key.
• The display changes to REMOTE.
2
Send the data to the plotter.
• On receiving the data, the plotter performs cutting
(plotting) while displaying the remaining amount of
the data.
• Upon completion of cutting (plotting), the display
changes as shown at right.
Bringing the cutting (plotting) to a halt
To temporarily stop the plotter during cutting (plotting), press the key once. Another press of the
key will make the plotter resume cutting (plotting).
• In case the sheet has slipped off the plotter during cutting operation, turn off the power
immediately; otherwise, the main unit may be damaged.
• The LCD will show the following error message if you try to execute any function that can
initiate some action during temporary suspension or any operation that can affect the
command coordinate system.
• If the error message appears, let the plotter complete the cutting for the remaining portion of
the data or discontinue the cutting by executing data clearing ( OPERATION MANUAL).
