Mindray cPM 12 User Manual

8-12
8.2.9.2 Parts List
SN Description FRU part number
1 Front housing of A3 module (2ch-IBP + C.O. + Microstream CO
2
) 801-9261-00028-00
2 Silicone tube
3 Double IBP receptacle (9281)
4 C.O._IBP interface board (Passport)
8 Module indicator and cable
31 C.O. module, single receptacle
5 Screw, self-tapping, PT3×8 /
6 IBP/C.O. signal cable (4-way) 009-002214-00
7 Cable between the Microstream CO
2
module and converter board 009-001992-00
9 Cable between the converter board and M03B module 009-001971-00
10 C.O./IBP (M03B) module M03B-30-26064
11 CO
2
bracket for A module /
12 IBP_CO_Microstream CO
2
main unit(FDA) 115-030771-00
13 Screw, pan head Phillips, M3×6 /
14 IBP insulator for A module /
15 A module button 043-001891-01
16 Spring washer /
17 Screw, pan head, Phillips, M3×8 /
18 Module label (no manufacturer information) /
19 External converter board (plug-in modules) 051-000874-00
20 Lock for A module 043-001892-01
21 Screw, Pan head with washer, Phillips M3×6 /
22 Rear housing of A modules 043-002103-01
23 Bracket for A module 043-001890-01
24 Cable between the converter board and copper board 009-001970-00
25 External module interface board (IBP_C.O._Microstream CO
2
) 801-9261-00020-00
External module interface board (Microstream CO
2
) 801-9261-00021-00
26 Connecting sheet for A1 module bracket /
27 Microstream CO
2
module connector /
28 Spring washer /
29 Nut, Stainless Steel M5 GB6170 /
30 Microstream CO
2
connector fixing spring /
32 Microstream CO
2
connector baffle /
33 Gas outlet /
34 Blank IBP socket 043-001893-01
