5-48 Image Optimization
Function: used to increase 2D image profile for better boundary details.
Selection: OFF, 1-7.
Function: the bigger the value is, the clearer the boundary of the image is.
Selection: only enabled in rendering mode Off, Low, Mid, High and Max.
Function: VR image becomes more stereoscopic. The render color in the VR
image corresponds to the depth color.
Selection: Off, Black, Cyna, Blue, Rose
Reset Curve
To reset the volume rotation, shifting and zooming to original status.
To reset the curve to be the beeline.
To reset volume to original orientation and original parameters.
Render Mode
Function: set Surface as VR rendering mode.
This is helpful for surface imaging, such as fetus face/hand or
foot.
Tips: you may have to adjust the threshold to obtain a clear
body boundary.
Function: set Max as VR rendering mode, displays the
maximum echo intensity in the observation direction.
This is helpful for viewing bony structures.
Function: set Min as VR rendering mode, displays the
minimum echo intensity in the observation direction.
This is helpful for viewing vessels and hollow structures.
Function: set X-ray as VR rendering mode. Displays the
average value of all gray values in the ROI.
X Ray: used for imaging tissues with different structure inside
or tissues with tumor.
iLive brings you a better imaging experience by adding
lighting rendering effect to the traditional way. It supports
global lighting mode as well as partial scattering mode,
allowing human tissue texture to be revealed more clearly.
The above five rendering manners can be applied to both gray and inversion
modes.
Where, inversion is to inverse the grayscale of the image, so as to enhance
observation for low-echo region, applicable for vessel, cyst and etc.
When the function is turned on, the rendering mode parameters change into
the corresponding inverse parameters.
