Mindray DC-80 User Manual

Image Optimization 5-101
2. Select the loop. Use the buttons displayed during Select Mode to designate another loop or
another view for display.
 Use [Stages] or [Views] on the soft menu to select the target stage/view.
 Single-click a clip to select the clip for current stage/view and zoom in the clip to the full-
screen.
 Double click a clip, the clip will be magnified.
 Tap [First/Last] or [Previous/Next] on the touch screen to display another loop in the
current view.
 Click buttons on the left side of the screen to view the cine files by frame.
3. Select the stage and view to display all loops for the view and then continue designating the
―preferred‖ loop for each displayed view until all views are completed.
Description of select mode pertinent controls:
Selection
Description
Stages
Rotate the corresponding knob under the button to select a stage.
Views
Rotate the corresponding knob under the button to select a view.
Acquire/ Select/
Review/WMS
To switch the mode status.
1. Clip/2. Clip/3. Clip/4. Clip
For selecting views in the selected stage.
Next
Next four Clips.
Previous
Previous four Clips.
First
Go to ―first‖ Clips.
Last
Go to ―last‖ Clips.
Prev/Next/First/Last frame
See previous/next/first/last frame of the cine file.
Speed decrease/Speed
increase
Decreases or increases playback speed.
Text
Function that turns on screen graphic text ―On‖/―Off‖.
Information includes: name of level, name of view, heart rate, time
stamp acquisition, timers, frame slider, loop ID, clip control. For the
cine without distributed view, name of level, name of view are
displayed in ―---‖.
Apply edit all
Clip edit applied to all clips taken.
Clip Length
Specify the clip segments: systole, diastole, full cycle or user-
defined.
Bookmark
For continuous acquisition, when bookmark is set ―On‖, only the
selected loops for the current view can be displayed.
Delete Unselected
Delete clips that are not selected. If selected, the system will delete
all clips that are not selected after the exam is ended.
Suspend
Pause the stress echo exam but not end the stress echo exam.
When stress echo exam is suspended, the user can perform image
acquisition of all other imaging modes, or perform operations like
measurement.
End SE exam
End the stress echo exam.

Mindray DC-80 Specifications

General

Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler, Tissue Doppler, 3D/4D Imaging
Probes	Convex, Linear, Phased Array, Volume
Advanced Features	Auto Optimization, Auto EF
Connectivity	DICOM 3.0, USB, HDMI, VGA, Ethernet
Transducer Ports	4
Applications	Abdominal, Cardiac, Obstetrics/Gynecology, Vascular, Small Parts, Musculoskeletal, Urology, Pediatrics, Neonatal
Transducer Types	Convex, Linear, Phased Array, Volume
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	30% to 80%
