Main Chassis Sub-assembly Isometric Drawings and Parts List
4 - 8 0070-10-0705 Passport V™ Service Manual
ITEM NO DESCRIPTION PART NUMBER
1 Interface Connector PCB Assembly 801-6100-00025-00
2 Cable from the interface board to CF card board 6100-20-86302
3 CF card assembly 801-6100-00012-00
4 Storage card CF card 1GB iCF4000 801-0000-00006-00
5 Speaker bolster plate 6100-20-86281
6 Fan service kit 801-6100-00013-00
7 Plate, Fan Retaining 6101-20-46731
8 Screw, Flat Head Phillips M3X25 M04-051172---
9 Module, Wireless AP 801-6100-00014-00
10 Retainer plate, speaker 6100-20-86280
11 Speaker gasket 6006-20-39418
12 Screw, Combined screw M3X8 N/A
13 Speaker cable 4ohm 2W 350mm 020-000001-00
14 Gasket, Speaker pressure plate and spacer 8002-20-36218
15 AC Inlet with Cable Assembly 9211-20-87221
16 Grounding terminal 0509-20-00098
17 Serrated lock washers external teeth GB/T862.2-1987 6
plated with anti-rustiness nickel
M04-021048---
18 Washer, Grounding pillar 6100-20-86393
19 Bracket, AC Inlet N/A
20 PCBA, Power Supply 801-6100-00015-00
21 Insulator, Power Supply Board N/A
22 Screw, Flat Head Phillips M3X6 N/A
23 Battery latch 6100-20-86255
24 Battery latch spring 6100-20-86252
25 Battery compartment overlay 6100-20-86406
26 Clapboard, battery (tool HM-070) 9000-20-07329
27 Screw, Flat Head Self-Tapping PT3X8 N/A
28 Bracket, Main N/A
29 Battery latch retaining plate N/A
30 Spring, EMI 0000-10-10996
31 PCBA, Li-Battery 801-6100-00016-00
32 Nut, Lock WasherM3 N/A
33 Cable Assembly, Recorder 9211-20-87228
34 Plate, Recorder Mounting N/A
35 Screw, Pan Head W/Washer Phillips M3X6 M04-004012---
To Next Page
