Mindray Passport V - Trends Troubleshooting; Printer;Recorder Troubleshooting

Troubleshooting Menus Repair Information
3 - 50 0070-10-0705 Passport V™ Service Manual
3.16.9 Trends Troubleshooting
3.16.10 Printer/Recorder Troubleshooting
GM: Unknown Agent 1 Appears when the system
detects a gas that does
not match the
spectroscopic signatures
of the five known
anesthetic agents.
1Use recognized agent.
Sampling Error 1 Appears when a
sampling error occurs on
one or more Gas Module
channels during
calibration.
1Repeat calibration
procedure. If problem
persists, contact Technical
Support.
Not Ready For Calibration 1 Appears when the Gas
Module is unable to
initialize calibration.
1Repeat calibration
procedure. If problem
persists, contact Technical
Support.
Zeroing Error 1 Appears when the Gas
Module cannot perform a
Zeroing during
calibration.
1Repeat calibration
procedure. If problem
persists, contact Technical
Support.
GM: Communication Error 1 System cannot
communicate correctly
with Resp module, and
receive the error data
packets.
1 Restart the monitor. If the
error still appears, please
contact Technical
Support.
GM: Disconnected 1 Appears when the
Passport V cannot
detect signals being sent
by the Gas Module.
1Ensure Gas Module is
turned on and interface
cable is properly
connected. If problem
persists, contact Technical
Support.
MESSAGE/ PROBLEM REASON SOLUTION
MESSAGE/ PROBLEM REASON SOLUTION
No Trends displayed 1 Trend page is scrolled. 1 Use scroll button in Trend
Menu to scroll to top of
Trend Menu.
Patient data is missing when
power cycling unit
1Data storage card
abnormal.
1Contact Technical
Support.
MESSAGE/ PROBLEM REASON SOLUTION
Recorder Report Appears
Totally Blank
1Thermal paper may be
installed incorrectly (up-
side down).
1Remove paper and re-
install with paper feeding
off of the spool from the
bottom.
Local Printer Door Open 1 The printer door is not
closed.
1Close the printer door.
Local Printer Out Of Paper 1 Printer out of paper. 1 Replace with a new roll of
paper.
