T1 Service Manual 2-11
2.5.3 External Parameter Modules
T1 can be configured with the following external modules:
 Sidestream CO
2
module
 Microstream CO
2
module
T1 is connected with the external modules through the T1 Handle.
T1
MainUnit
ExternalModule
Rack
NIOS
Board
Rack
Conver
ter
Board
P
l
u
g
54pin
Serialport
If T1 and an external module are both installed to the T1 handle, the external module is connected to the T1 handle converter
board through the T1 handle NIOS board gets power from the battery installed in T1. The T1 handle converter is connected to
T1 through the 54 pin connector. The T1 Handle can be installed to the T1 Docking station and be powered by the Docking
Station.
