5-6 T1 Service Manual
5.3.5 SpO
2
Test
Tool Required:
 None.
Follow this procedure to perform the test:
1. Connect SpO
2
sensor to the SpO
2
connector of the monitor. Set [Patient Cat.] to [Adu] and [PR Source] to SpO
2
on the
monitor.
2. Apply the SpO
2
sensor to the ring finger of a healthy person.
3. Check the Pleth wave and PR reading on the screen and make sure that the displayed SpO2 is within 95% and 100%. If
you are unable to get the SPO
2
between 95% and 100%, contact Mindray Technical Support.
4. Remove the SpO
2
sensor from the finger and make sure that an alarm of SpO
2
Sensor Off is triggered.
NOTE
 A functional tester cannot be used to assess the accuracy of a pulse oximeter monitor. However, it can be used to
demonstrate that a particular pulse oximeter monitor reproduces a calibration curve that has been
independently demonstrated to fulfill a particular accuracy specification.
5.3.6 NIBP Tests
5.3.6.1 NIBP Accuracy Test
Tools required:
 T-shape connector
 Appropriate tubing
 Squeeze bulb
 Rigid Vessel with volume 500 ± 25 ml
 Reference manometer (calibrated with accuracy equal to or better than 0.75 mmHg)
