3-4 T1 Service Manual
3.2.3 Wireless Network Specification
Network standard IEEE 802.11a/b/g/n
Modulation mode DSSS and OFDM
Operating frequency
For 2.4G frequency bands (FCC): 2.4GHz to 2.483GHz (only when Channels 1 to 11 are in
use)
For5G frequency bands (FCC): 5.15GHz to 5.35GHz, 5.725GHz to5.82GHz
QoS
QoS Supported. Real time monitoring data transmission priority can be configured with
a higher priority than other data transmission.
Channel spacing
IEEE 802.11a: 20MHz
IEEE 802.11b/g: 5MHz
IEEE 802.11n at 2.4 GHz: 5MHz
IEEE 802.11n at 5 GHz: 20MHz
Wireless baud rate
IEEE 802.11a: 6 to 54 Mbps
IEEE 802.11b: 1to11 Mbps
IEEE 802.11g: 6 to 54 Mbps
IEEE 802.11n (at both 2.4GHz and 5GHz): 6.5 to 72.2 Mbps
Output power
< 30 dBm (FCC requirement: detection mode – peak power)
< 20 dBm (CE requirement: detection mode – RMS)
Data security
Security standards: WPA-PSK, WPA2-PSK, WPA-Enterprise/WPA2-Enterprise
EAP methods: PEAP-MsCHAPv2, PEAP-GTC, PEAP-TLS, EAP-TTLS, EAP-TLS, EAP-FAST,
EAP-LEAP
Encryption modes: TKIP and AES
Roaming Supported
System capacity
Number of T1 monitors supported by a single AP: ≤ 16. Each T1 monitor can
communicate with the central station and connect to two other monitors at the same
time, and among them, at most two T1 monitors can transmit history data (the
Panorama central station does not transfer the historical data.) when reconnection at
the same time. The wireless functions of all T1 monitors are normal at the same time.
Resistance to wireless interference
The wireless functions of the monitor are normal when the following conditions exist
simultaneously:
1. The distance between interfering devices (including wireless devices at the
frequency of 2.4GHz such as cellular communication devices, microwave ovens,
intercoms, cordless phones and electro-surgical units, excluding Wi-Fi) and the
monitor is greater than 20 cm.
2. Co-channel interference (CCI) on the Wi-Fi network should be no greater than
-85dBm.
3. Adjacent–channel interference (ACI) on the Wi-Fi network should be no greater
than -50dBm.
FCC approval SQG-MSD45N
