T1 Service Manual 7-1
7 Disassembly and Repair
7.1 Tools Required
To disassemble and replace the parts and components, the following tools may be required:
 Number 2 Philips screwdriver
 3 mm hex driver
 Tweezers
 Needle nose pliers
7.2 Preparations for Disassembling
Before disassembling the equipment, do the following:
 Stop patient monitoring, turn off the equipment, and disconnect all the accessories and peripheral devices.
 Disconnect the DC power source and remove the battery.
CAUTION
 Before disassembling the equipment, be sure to eliminate any static charges first. When disassembling the
PCBAs and parts labeled with static-sensitive symbols, make sure you are wearing electrostatic discharge
protection such as an anti-static wristband or gloves to avoid damaging the equipment.
 Properly connect and route the cables and wires when reassembling the equipment to avoid short circuits.
 Select appropriate screws to assemble the equipment.
 Follow the proper sequence when disassembling the equipment.
 Disconnect all the cables before disassembling any parts. Be careful not to damage any cables or connectors.
 Place removed screws and disassembled parts properly, preventing them from being lost or contaminated.
 Place the screws and parts from the same module together to facilitate reassembling.
 To reassemble the equipment, first assemble the assemblies, and then the main unit. Carefully route the
cables.
 Make sure all O rings and seals are installed during reassembling.
