Mindray TE5 User Manual

2-4 System Overview
Probe
model
Probe Type
Intended Use
Region Applied
P7-3s
Phased
Abdominal, pediatric, neonatal cephalic, adult
cephalic, cardiac adult, cardiac pediatric
Body surface
SP5-1s
Phased
Fetal, Abdominal, Pediatric, Neonatal
Cephalic, Adult Cephalic, Cardiac Adult,
Cardiac Pediatric
Body surface
L9-3s
Linear
Abdominal, Pediatric, small organ (breast,
thyroid, testes), musculo-skeletal
(conventional, superficial), Peripheral vessel
Body surface
L11-
3VNs
Linear
Abdominal, Pediatric, small organ (breast,
thyroid, testes), musculo-skeletal
(conventional, superficial), Peripheral vessel
Body surface
C5-1s
Convex
Fetal, Abdominal, Pediatric, Peripheral vessel
Body surface
C4-1s
Convex
Fetal, Abdominal, Pediatric, Musculo-skeletal
(Conventional), Cardiac Adult
Body surface
L14-5Ws
Linear
Abdomen, Pediatric, small organ (breast,
thyroid, testes), musculo-skeletal
(conventional, superficial), Peripheral vessel
Body surface
L12-
3RCs
Linear
Abdominal, Pediatric, small organ (breast,
thyroid, testes), musculo-skeletal
(conventional, superficial), Peripheral vessel
Body surface
Some of the probes have corresponding needle-guided brackets for biopsy. The available probes
and the corresponding needle-guided brackets are listed as follows:
Probe model
Needle-guided
Bracket Model
Biopsy
angle/depth
(±1°)
Applicable Biopsy Needle
V11-
3Ws/6CV1s
NGB-004
metal/needle
non-detachable
/
16G, 17G, 18G
L12-4s/ L7-3s/
L14-6Ns/ 7L4s
NGB-007
plastic/needle
detachable
metal/needle
detachable
40°, 50°, 60°
Metal: 14G, 16G, 18G, 20G, 22G
Plastic: 13G, 15G, 16G, 18G, 20G
7LT4s
NGB-010
(metal/needle
detachable)
30°, 40°, 50°
13G, 15G, 16G, 18G, 20G
P4-2s/SP5-1s
NGB-011
metal/needle
non-detachable
11°, 23°
13G, 15G, 16G, 18G, 20G
C5-2s
NGB-015
Metal/needle
detachable
25°, 35°, 45°
14G, 16G, 18G, 20G, 22G
