Mindray TE5 User Manual

System Preparation 3-7
3.4.2 Disconnecting a probe
1. Turn the locking lever to the right position to unlock the connector.
2. Pull the probe connector straight out as shown in the figure below.
3.5 Connecting the Footswitch
WARNING:
DO NOT connect more than one wireless
footswitch receiver to the ultrasound system at
the same time; otherwise, malfunction may result.
The system supports USB port-type footswitches and wireless type footswitches.
The function of the foot switch can be preset. See chapter “12.1.6 Footswitch” for details.
3.6 Connecting USB Devices
WARNING:
DO NOT directly remove a USB memory device,
as the USB device and/or the system may become
damaged.
 When connecting a USB memory device to the ultrasound system via a USB port, a sound is
heard if it is connected successfully and the symbol appears in the top-right corner of the
screen.
 To remove the USB device: tap to open the [Remove USB Device] screen. Select the
device to be removed and tap [OK]. A sound is heard when removing the USB memory device.
 The system supports option of external DVD R/W drive. The DVD R/W drive is connected to
the ultrasound system via USB port.
NOTE:
If the USB flash drive cannot be recognized by the system, please try disconnecting
and then connecting again several times, or try another USB flash drive. If the problem
still exists, please contact Mindray service engineer.
